Appendix B Accessories|

B-6

Revision Nov. 2008, VLE1, SW V1.03

Order P/N: BR1K0W050, BR1K2W008, BR1K2W6P8, BR1K5W005, BR1K5W040

B.1.2 Specifications for Brake Unit

230V Series

460V Series


2015

2022

4030 4045

4132

Max. Motor Power (kW)

15

22

30

45

132

Max. Peak Discharge Current

(A) 10%ED

40 60 40 60

240

Continuous Discharge Current

(A)

15 20 15 18

75

Outpu

t

Rating

Brake Start-up Voltage (DC)

330/345/360/380

/400/415±3V

660/690/720/760/

800/830±6V

618/642/667/690

/725/750±6V

Inpu

t

Rating

DC Voltage

200~400VDC

400~800VDC

Heat Sink Overheat

Temperature over +95

°C (203

o

F)

Alarm Output

Relay contact 5A 120VAC/28VDC (RA, RB, RC)

Prote

cti

on

Power Charge Display

Blackout until bus (+~-) voltage is below 50VDC

Installation Location

Indoor (no corrosive gases, metallic dust)

Operating Temperature

-10

°C ∼ +50°C (14

o

F to 122

o

F)

Storage Temperature

-20

°C ∼ +60°C (-4

o

F to 140

o

F)

Humidity 90%

Non-condensing

Environmen

t

Vibration

9.8m/s

2

(1G) under 20Hz

2m/s

2

(0.2G) at 20~50Hz

Wall-mounted Enclosed Type

IP50

IP10
