Chapter 4 Parameters|

Revision Nov. 2008, VLE1, SW V1.03 4-53

It is used to set the corresponding ACI voltage of the external analog input 0.

03-05

Analog Input Bias 1 (AUI2)

Unit: 0.1

Control

mode

VF

VFPG

SVC

FOCPG TQCPG FOCPM

Factory setting: 0.0

Settings

-100.0~100.0%

It is used to set the corresponding AUI2 voltage of the external analog input 0.

The relation between external input voltage/current and setting frequency is equal to -10~+10V

(4-20mA) corresponds to 0-60Hz.

03-06

Positive/negative Bias Mode (AUI1)

Control

mode

VF

VFPG

SVC

FOCPG TQCPG FOCPM

Factory setting: 0

03-07

Positive/negative Bias Mode (ACI)

Control

mode

VF

VFPG

SVC

FOCPG TQCPG FOCPM

Factory setting: 0

03-08

Positive/negative Bias Mode (AUI2)

Control

mode

VF

VFPG

SVC

FOCPG TQCPG FOCPM

Factory setting: 0

Settings

0

Zero

bias

1

Lower than bias=bias

2

Greater

than

bias=bias

3

The absolute value of the bias voltage while serving as the center

4

Serve bias as the center

In a noisy environment, it is advantageous to use negative bias to provide a noise margin. It is

recommended NOT to use less than 1V to set the operating frequency.

03-09

Analog Input Gain 1 (AUI1)

Unit: 0.1

Control

mode

VF

VFPG

SVC

FOCPG TQCPG FOCPM

Factory setting: 100.0

03-10

Analog Input Gain 1 (ACI)

Unit: 0.1

Control

mode

VF

VFPG

SVC

FOCPG TQCPG FOCPM

Factory setting: 100.0

03-11

Analog Input Gain 1 (AUI2)

Unit: 0.1

Control

mode

VF

VFPG

SVC

FOCPG TQCPG FOCPM

Factory setting: 100.0

Settings

-500.0~500.0%
