Chapter 4 Parameters|
4-72 Revision Nov. 2008, VLE1, SW V1.03
Bit0 Bit1 Bit2 Bit3 Bit4 Bit5 Bit6
Fault code
current Volt. OL SYS FBK EXI CE
15: Phase loss (PHL) ●
16: IGBT heat sink over-heat (oH1) ●
17: Heat sink over-heat (oH2)(for
40HP above) ●
18: TH1 open loop error (tH1o) ●
19: TH2 open loop error (tH2o) ●
20: Fan error signal output ●
21: over-load (oL) (150% 1Min) ●
22: Motor 1 over-load (EoL1) ●
23: Reserved
24: Motor PTC overheat (oH3) ●
25: Reserved
26: over-torque 1 (ot1) ●
27: over-torque 1 (ot2) ●
28: Reserved
29: Reserved
30: Memory write-in error (cF1) ●
31: Memory read-out error (cF2) ●
32: Isum current detection error (cd0) ●
33: U-phase current detection error
(cd1) ●
34: V-phase current detection error
(cd2) ●
35: W-phase current detection error
(cd3) ●
36: Clamp current detection error
(Hd0) ●
37: Over-current detection error (Hd1) ●
38: Over-voltage detection error (Hd2) ●
