Appendix B Accessories|
B-34 Revision Nov. 2008, VLE1, SW V1.03
Terminal Symbols Descriptions Specifications
J4
Grounding
Connected to the grounding of the power
of the AC motor drive and used for PG
shielding
4. Output Signal Setting of the Frequency Divider
It generates the output signal of division factor
“n” after dealing with the input pulse. Please
set by the switch SW1 on the card.
ON
1 2 3 4 5 1
RS
T
Division Factor
BI
T0
BI
T1
BI
T2
BI
T3
BI
T4
0
1
ON
O/
M
OD
E
O/MODE: output type setting of the division
pulse
RST: clock reset bit
Division factor: setting for division factor n:
1~31
Settings and explanations
Division factor
O/MO
DE
A leads B B leads A
0
A
B
A/O-/A/O
B/O-/B/O
OA-GND
OB-GND
A
B
A/O-/A/O
B/O-/B/O
A/O-/A/O
B/O-/B/O
OA-GND
OB-GND
1
A
B
A/O-/A/O
B/O-/B/O
A/O-/A/O
B/O-/B/O
OA-GND
OB-GND
A
B
A/O-/A/O
B/O-/B/O
A/O-/A/O
B/O-/B/O
OA-GND
OB-GND
