Chapter 4 Parameters|
Revision Nov. 2008, VLE1, SW V1.03 4-79
07-19 Source of Torque Offset
Control
mode
SVC FOCPG TQCPG FOCPM
Factory Setting: 0
Settings 0 Disable
1 Analog input (Pr.03-00)
2 Torque offset setting (Pr.07-20)
3 Control by external terminal (by Pr.07-21 to Pr.07-23)
This parameter is the source of torque offset.
When it is set to 3, the source of torque offset will decide to Pr.07-21, Pr.07-22 and Pr.07-23
by the multi-function input terminals setting (19, 20 or 21).
02-01~02-08 is set to 19 02-01~02-08 is set to 20 02-01~02-08 is set to 21 Torque offset
OFF OFF OFF None
OFF OFF ON 07-25
OFF ON OFF 07-24
OFF ON ON 07-25+07-24
ON OFF OFF 07-23
ON OFF ON 07-23+07-25
ON ON OFF 07-23+07-24
ON ON ON 07-23+07-24+07-25
07-20 Torque Offset Setting Unit: 0.1
Control
mode
SVC FOCPG TQCPG FOCPM
Factory Setting: 0.0
Settings 0.0 to 100.0%
This parameter is torque offset. The motor rated torque is 100%.
07-21 High Torque Offset Unit: 0.1
Control
mode
SVC FOCPG TQCPG FOCPM
Factory Setting: 30.0
Settings 0.0 to 100.0%
07-22 Middle Torque Offset Unit: 0.1
Control
mode
SVC FOCPG TQCPG FOCPM
Factory Setting: 20.0
Settings 0.0 to 100.0%
