Delta Electronics Elevator Drive VFD-VL User Manual
Page 111
Chapter 4 Parameters|
4-56
Revision Nov. 2008, VLE1, SW V1.03
Group 4 Multi-Step Speed Parameters
04-00
Zero Step Speed Frequency
Unit: 0.01
04-01
1st Step Speed Frequency
Unit: 0.01
04-02
2nd Step Speed Frequency
Unit: 0.01
04-03
3rd Step Speed Frequency
Unit: 0.01
04-04
4th Step Speed Frequency
Unit: 0.01
04-05
5th Step Speed Frequency
Unit: 0.01
04-06
6th Step Speed Frequency
Unit: 0.01
04-07
7th Step Speed Frequency
Unit: 0.01
04-08
8th Step Speed Frequency
Unit: 0.01
04-09
9th Step Speed Frequency
Unit: 0.01
04-10
10th Step Speed Frequency
Unit: 0.01
04-11
11th Step Speed Frequency
Unit: 0.01
04-12
12th Step Speed Frequency
Unit: 0.01
04-13
13th Step Speed Frequency
Unit: 0.01
04-14
14th Step Speed Frequency
Unit: 0.01
04-15
15th Step Speed Frequency
Unit: 0.01
Control
mode
VF
VFPG
SVC
FOCPG FOCPM
Factory setting: 0.00
Settings
0.00 to 120.00 Hz
The Multi-Function Input Terminals (refer to Pr.02-01 to 02-08) are used to select one of the
AC motor drive Multi-step speeds. The speeds (frequencies) are determined by Pr.04-00 to
04-15 as shown above.
