Chapter 3 Operation and Start Up|
3-10 Revision Nov. 2008, VLE1, SW V1.03
NOTE 4: It will display “Auto Tuning Err” on the keypad when stopping by the fault of the
AC motor drive or human factor to show the failed detection. At this moment, please check
the connections of the wirings of the AC motor drives. If it displays “PG Fbk Error” on the
digital keypad, please change the setting of Pr.10-02 (if it is set to 1, please change it to 2).
If it displays “PG Fbk Loss” on the digital keypad, please check the feedback of Z-phase
pulse.
Pr.10-00
PG signal type
0: No function
1: ABZ
2: ABZ+Hall
3: SIN/COS+Sinusoidal
4: SIN/COS+Endat
5: SIN/COS
6: SIN/COS + Hiperface
„ Encoder settings: Pr.10-01~Pr.10-02
Detection for the magnetic pole position of motor
The detection method will be different by the setting of Pr.10-00 PG Signal Type.
The detection methods: (refer to Pr.10-00)
1. Setting 1 or 5: The AC motor drive will output short circuit to detect the position of the
electromagnetic pole. At this moment, the motor will generate a little noise.
2. Setting 2: The AC motor drive will detect the position of the electromagnetic pole by the
UVW signal of PG.
3. Setting 3: The AC motor drive will detect the position of the electromagnetic pole by the
sine signal of PG.
4. Setting 4: The AC motor drive will detect the position of the electromagnetic pole by the
communication signal of PG.
Reference table for tuning
Setting of PG
signal type
PG signal type Applicable PG card Pr.08-00=1 Pr.08-00=3
10-00=1 A, B, Z EMVL-PGABO/ABL Motor will run Motor will run
10-00=2 A, B, Z+U, V, W EMVL-PGABL Motor will run Motor won’t run
10-00=3
SIN/COS+
Sinusoidal
EMVL-PGH01/02 Motor will run Motor will run
10-00=4 SIN/COS+Endat EMVL-PGS01 Motor will run Motor won’t run
10-00=5 SIN/COS EMVL-PGH01/02 Motor will run Motor will run
10-00=6
SIN/COS +
Hiperface
EMVL-PGS01 Motor will run Motor won’t run
Pr.10-01
Encoder Pulse
1~25000
