Chapter 4 Parameters|
4-50 Revision Nov. 2008, VLE1, SW V1.03
02-33 Output Current Level Setting for External Terminals Unit:1
Control
mode
VF VFPG SVC FOCPG TQCPG FOCPM
Factory setting: 0
Settings 0~100%
When output current is >= Pr.02-33, it will activate multi-function output terminal (Pr.02-11 to
Pr.02-22 is set to 27).
When output current is < Pr.02-33, it will activate multi-function output terminal (Pr.02-11 to
Pr.02-22 is set to 28).
02-34 Output Boundary for External Terminals Unit:0.01
Control
mode
VF VFPG SVC FOCPG TQCPG FOCPM
Factory setting: 0.00
Settings 0.00~ ±120.00Hz
When output frequency is >=02-34, it will activate the multi-function terminal (Pr.02-11 to
Pr.02-22 is set to 29).
When output frequency is <02-34, it will activate the multi-function terminal (Pr.02-11 to Pr.02-
22 is set to 30).
02-35 Detection Time of Mechanical Brake Unit: 0.01
Control
mode
VF VFPG SVC FOCPG TQCPG FOCPM
Factory setting: 0.00
Settings 0.00 ~ 10.00 sec
When mechanical brake function (setting 42 of Pr.02-01~02-08) is not enabled within this
setting time, it will display fault code 64 (MBF) mechanical brake error.
