Chapter 3 Operation and Start Up|
Revision Nov. 2008, VLE1, SW V1.03 3-11
Pr.10-02
Encoder Input Type Setting
0: Disable
1: Phase A leads in a forward run command and
phase B leads in a reverse run command
2: Phase B leads in a forward run command and
phase A leads in a reverse run command
3: Phase A is a pulse input and phase B is a
direction input. (low input=reverse direction, high
input=forward direction)
4: Phase A is a pulse input and phase B is a
direction input. (low input=forward direction, high
input=reverse direction)
5: Single-phase input
3.3.2.4 Step 4
Multi-step speed settings
„ Please confirm the total speed steps (high speed, middle speed, low speed, creep,
inspection and level auto-learning)
„ Please make sure that the setting of step speeds and the action of the corresponding
terminals of multi-function input commands are correct.
„ Setting multi-step speeds in Pr.04-00 to Pr.04-15
NOTE: It is recommended to set the max. operating frequency to the half of max. operating
frequency before confirming the setting of each step speed and the action of the
corresponding terminals of multi-function input commands.
Zero Step Speed Frequency 0.00~120.00Hz
1st Step Speed Frequency 0.00~120.00Hz
2nd Step Speed Frequency 0.00~120.00Hz
3rd Step Speed Frequency 0.00~120.00Hz
4th Step Speed Frequency 0.00~120.00Hz
5th Step Speed Frequency 0.00~120.00Hz
6th Step Speed Frequency 0.00~120.00Hz
7th Step Speed Frequency 0.00~120.00Hz
8th Step Speed Frequency 0.00~120.00Hz
9th Step Speed Frequency 0.00~120.00Hz
10th Step Speed Frequency 0.00~120.00Hz
11th Step Speed Frequency 0.00~120.00Hz
12th Step Speed Frequency 0.00~120.00Hz
13th Step Speed Frequency 0.00~120.00Hz
14th Step Speed Frequency 0.00~120.00Hz
Settings of Pr.04-00 to Pr.04-15
15th Step Speed Frequency 0.00~120.00Hz
