Chapter 4 Parameters|
4-70 Revision Nov. 2008, VLE1, SW V1.03
Bit 3 Bit 2 Bit 1 Bit 0 Fault code
9: Over-voltage during constant speed (ovn)
10: Over-voltage at stop (ovS)
11: Low-voltage during acceleration (LvA)
12: Low-voltage during deceleration (Lvd)
13: Low-voltage during constant speed (Lvn)
14: Low-voltage at stop (LvS)
0 0 1 1
15: Phase loss (PHL)
16: IGBT heat sink over-heat (oH1)
17: Heat sink over-heat (oH2)(for 40HP above)
18: TH1 open loop error (tH1o)
0 1 0 0
19: TH2 open loop error (tH2o)
1 0 0 0 20: Fan error signal output
0 1 0 1 21: over-load (oL) (150% 1Min)
22: Motor 1 over-load (EoL1)
0 1 1 0
24: Motor PTC overheat (oH3)
26: over-torque 1 (ot1)
0 1 1 1
27: over-torque 1 (ot2)
30: Memory write-in error (cF1)
31: Memory read-out error (cF2)
32: Isum current detection error (cd0)
33: U-phase current detection error (cd1)
34: V-phase current detection error (cd2)
35: W-phase current detection error (cd3)
36: Clamp current detection error (Hd0)
37: Over-current detection error (Hd1)
38: Over-voltage detection error (Hd2)
1 0 0 0
39: Ground current detection error (Hd3)
1 0 0 1 40: Auto tuning error (AuE)
41: PID feedback loss (AFE)
42: PG feedback error (PGF1)
1 0 1 0
43: PG feedback loss (PGF2)
0 1 1 1 44: PG feedback stall (PGF3)
45: PG slip error (PGF4)
46: PG ref input error (PGr1)
47: PG ref loss (PGr2)
1 0 1 0
48: Analog current input error (ACE)
49: External fault input (EF)
1 0 1 1
50: Emergency stop (EF1)
1 0 0 1 52: Password error (PcodE)
54: Communication error (cE1)
55: Communication error (cE2)
56: Communication error (cE3)
57: Communication error (cE4)
58: Communication Time-out (cE10)
1 1 0 0
59: PU time-out (cP10)
1 0 0 0 60: Brake chopper error (bF)
63: Safety loop error (Sry)
1 0 1 1
64: Mechanical brake error (MBF)
1 0 0 0 65: PGF5 hardware error
