Chapter 3 Operation and Start Up|
Revision Nov. 2008, VLE1, SW V1.03 3-7
Settings of Pr.02-
13~02-22
19: Brake chopper output error
20: Warning output
21: Over voltage warning
22: Over-current stall prevention warning
23: Over-voltage stall prevention warning
24: Operation mode indication (Pr.00-15≠0)
25: Forward command
26: Reverse command
27: Output when current >= Pr.02-33
28: Output when current < Pr.02-33
29: Output when frequency >= Pr.02-34
30: Output when frequency < Pr.02-34
31-32: Reserved
33: Zero speed (actual output frequency)
34: Zero speed with Stop (actual output frequency)
35: Error output selection 1 (Pr.06-22)
36: Error output selection 2 (Pr.06-23)
37: Error output selection 3 (Pr.06-24)
38: Error output selection 4 (Pr.06-25)
39: Reserved
40: Speed attained (including zero speed)
41: Reserved
3.3.2.2 Step 2
Motor tuning
„ Setting the parameters according to the motor type (PM or IM)
IM motor
„ Inputting the nameplate information on the motor into Pr.01-00~01-02 and Pr.05-01~05-
04
Pr.01-00
Maximum Output Frequency 10.00~120.00Hz
Pr.01-01
1st Output Frequency Setting 1
(base frequency/motor rated
frequency) 0.00~120.00Hz
Pr.01-02
1st Output Voltage Setting 1
(base voltage/motor rated
voltage) 230V: 0.1V~255.0V
460V: 0.1V~510.0V
