Chapter 4 Parameters|
4-58 Revision Nov. 2008, VLE1, SW V1.03
4. The rated speed can’t be larger or equal to 120f/p. (f: output frequency Pr.01-01, p: Number of
Motor Poles Pr.05-04)
05-01 Full-load Current of Motor
Control
mode
VF VFPG SVC FOCPG TQCPG
Factory setting: #.##
Settings 40 to 120%
This value should be set according to the rated frequency of the motor as indicated on the
motor nameplate. The factory setting is 90% X rated current.
Example: if the rated current for 7.5hp (5.5kW) models is 25A and the factory setting is 22.5A.
In this way, the current range will be from 10A (25*40%) to 30A (25*120%).
05-02 Rated Power of Motor Unit: 0.01
Control
mode
SVC FOCPG TQCPG
Factory setting: #.##
Settings 0.00 to 655.35 kW Factory Setting: #.##
It is used to set rated power of the motor. The factory setting is the power of the drive.
05-03 Rated Speed of Motor (rpm) Unit: 1
Control
mode
VFPG SVC FOCPG TQCPG Factory setting: 1710
Settings 0 to 65535 rpm
It is used to set the rated speed of the motor and need to set according to the value indicated
on the motor nameplate.
05-04 Number of Motor Poles
Control
mode
VF VFPG SVC FOCPG TQCPG
Factory setting: 4
Settings 2 to 48
It is used to set the number of motor poles (must be an even number).
05-05 No-load Current of Motor Unit: Amp
Control
mode
VFPG SVC FOCPG TQCPG
Factory setting: #.##
Settings 0 to 100%
The factory setting is 40% X rated current.
