Revision Nov. 2008, VLE1, SW V1.03 A-1
Appendix A Specifications
There are 230V and 460V models for customers to choose by their requirement.
Voltage Class 230V Class
Model Number VFD-XXXVL 055 075 110 150 185 220 300 370
Max. Applicable Motor Output (kW) 5.5 7.5 11 15 18.5 22 30 37
Max. Applicable Motor Output (hp) 7.5 10 15 20 25 30 40 50
Rated Output Capacity (kVA) 9.5 12.5 19 25 29 34 46 55
Rated Output Current for
General Purposes (A)
21.9 27.1 41.1 53 70 79 120 146
**Rated Output Current for
Elevators (A)
25 31 47 60 80 90 150 183
Maximum Output Voltage (V) 3-Phase Proportional to Input Voltage
Output Frequency (Hz) 0.00~120.00 Hz
Outp
ut Rati
ng
Carrier Frequency (kHz) 12kHz 9kHz
Rated Input Current (A) 25 31 47 60 80 90 106 126
Rated Voltage/Frequency
3-phase
200-240V, 50/60Hz
Voltage Tolerance ±10%(180~264 V)
Inpu
t Ratin
g
Frequency Tolerance ±5%(47~63 Hz)
Cooling Method Fan Cooled
Weight (kg) 8 10 10 13 13 13 36 36
Voltage Class 460V Class
Model Number VFD-XXXVL 055 075 110 150 185 220 300 370 450 550 750
Max. Applicable Motor Output (kW) 5.5 7.5 11 15 18.5 22 30 37 45 55 75
Max. Applicable Motor Output (hp) 7.5 10 15 20 25 30 40 50 60 75 100
Rated Output Capacity (kVA) 9.9 13.7 18 24 29 34 46 56 69 80 100
Rated Output Current for
General Purposes (A)
12.3 15.8 21 27 34 41 60 73 91 110 150
**Rated Output Current for
Elevators (A)
14 18 24 31 39 47 75 91 113 138 188
Maximum Output Voltage (V) 3-phase Proportional to Input Voltage
Output Frequency (Hz) 0.00~120.00 Hz Outp
ut Rati
ng
Carrier Frequency (kHz) 15kHz 9kHz 6kHz
Rated Input Current (A) 14 18 24 31 39 47 56 67 87 101 122
Rated Voltage 3-phase 380 to 480 V, 50/60Hz
Voltage Tolerance ±10%(342~528 V)
Inpu
t Ratin
g
Frequency Tolerance ±5%(47~63 Hz)
Cooling Method Fan Cooled
Weight (kg) 8 10 10 13 13 13 36 36 36 50 50
