Chapter 1 Introduction|
Revision Nov. 2008, VLE1, SW V1.03 1-13
1.3 Dimensions
Frame C
C heck to be s ure that t he voltage of the m ain AC pow er
supply satis fies t he rat ed voltage of the I nverter.
D o not c onnect AC power t o output ter minals U /T 1,
V/T 2 and W /T 3.
R is k of electr ical s hock. Wait 10 m inutes after rem oving
pow er before servic ing.
U se proper gr ounding techniques.
R ead the us er manual before operation.
WARNING
W
W1
H
H2 H1
H3
D
1 3 2
Unit: mm [inch]
Frame W W1 H H1 H2 H3 D Ш Ш1 Ш2 Ш3
C
235
[9.25]
204
[8.03]
350
[13.78]
337
[13.27]
320
[12.60]
-
136
[5.35]
6.5
[0.26]
-
34
[1.34]
22
[0.87]
NOTE
Frame C: VFD055VL23A/43A, VFD075VL23A/43A, VFD110VL23A/43A
