Chapter 4 Parameters|
Revision Nov. 2008, VLE1, SW V1.03 4-13
Group 7 Special Parameters
Pr. Explanation Settings
Factory
Setting
VF
VF
PG
SVC
FOC
PG
TQC
PG
FOC
PM
07-00
Brake Chopper Level 230V: 350.0~450.0Vdc
460V: 700.0~900.0Vdc 380.0
760.0 ○ ○ ○ ○ ○ ○
07-01
Brake ED Value Setting 0~100% 100 ○ ○ ○ ○ ○ ○
07-02
DC Brake Current Level 0~100% 0 ○ ○ ○
07-03
DC Brake Time during Start-
up 0.0~60.0 sec 0.0 ○ ○ ○ ○ ○
07-04
DC Brake Time during
Stopping 0.0~60.0 sec 0.0 ○ ○ ○ ○ ○
07-05 Start-point for DC Brake 0.00~120.00Hz 0.00 ○ ○ ○ ○
07-06
DC Brake Proportional Gain 1~500Hz 50 ○ ○ ○
07-07
Dwell Time at Accel. 0.00~600.00sec 0.00 ○ ○ ○ ○ ○
07-08
Dwell Frequency at Accel. 0.00~120.00Hz 0.00 ○ ○ ○ ○ ○
07-09
Dwell Time at Decel. 0.00~600.00sec 0.00 ○ ○ ○ ○ ○
07-10
Dwell Frequency at Decel. 0.00~120.00Hz 0.00 ○ ○ ○ ○ ○
07-11
Fan Control 0: Fan always ON
1: 1 minute after AC motor drive stops, fan will be OFF
2: AC motor drive runs and fan ON, AC motor drive stops and
fan OFF
3: Fan ON to run when preliminary heat sink temperature
attained
4: Fan always OFF 2 ○ ○ ○ ○ ○ ○
07-12
Torque Command -100.0~100.0% (Pr. 07-14 setting=100%) 0.0 ○
07-13
Torque Command Source 0: Digital keypad (KPVL-CC01)
1: RS485 serial communication (RJ-11)
2: Analog signal (Pr.03-00) 2 ○
07-14
Maximum Torque Command 0~500% 100 ○ ○ ○ ○ ○ ○
07-15
Filter Time of Torque
Command 0.000~1.000 sec 0.000 ○
07-16 Speed Limit Selection 0: By Pr.07-17 and Pr.07-18
1: Frequency command source (Pr.00-14) 0 ○
07-17
Torque Mode +Speed Limit 0~120% 10 ○
07-18
Torque Mode-Speed Limit 0~120% 10 ○
07-19
Source of Torque Offset 0: Disable
1: Analog input (Pr.03-00)
2: Torque offset setting (Pr.07-20)
3: Control by external terminal (by Pr.07-21 to Pr.07-23) 0 ○ ○ ○ ○
07-20
Torque Offset Setting 0.0~100.0% 0.0 ○ ○ ○ ○
07-21
High Torque Offset 0.0~100.0% 30.0 ○ ○ ○ ○
07-22
Middle Torque Offset 0.0~100.0% 20.0 ○ ○ ○ ○
07-23
Low Torque Offset 0.0~100.0% 10.0 ○ ○ ○ ○
07-24
Forward Motor Torque Limit 0~500% 200 ○ ○ ○
07-25
Forward Regenerative
Torque Limit 0~500% 200 ○ ○ ○
07-26
Reverse Motor Torque Limit 0~500% 200 ○ ○ ○
07-27
Reverse Regenerative
Torque Limit 0~500% 200 ○ ○ ○
07-28
Emergency Stop (EF) &
Forced Stop Selection 0: Coast to stop
1: By deceleration Time 1
2: By deceleration Time 2
3: By deceleration Time 3
4: By deceleration Time 4
5: By Pr.01-31 0 ○ ○ ○ ○ ○ ○
07-29
Time for Decreasing Torque
at Stop 0.000~1.000 sec 0.000 ○ ○ ○
