Chapter 4 Parameters|
4-38 Revision Nov. 2008, VLE1, SW V1.03
02-02 Multi-Function Input Command 2 (MI2)
Factory Setting: 2
02-03 Multi-Function Input Command 3 (MI3)
Factory Setting: 3
02-04 Multi-Function Input Command 4 (MI4)
Factory Setting: 4
02-05 Multi-Function Input Command 5 (MI5)
Factory Setting: 0
02-06 Multi-Function Input Command 6 (MI6)
Factory Setting: 0
02-07 Multi-Function Input Command 7 (MI7)
Factory Setting: 0
02-08
Multi-Function Input Command 8 (MI8)
(specific terminal for Enable)
Factory Setting: 0
Settings 0-43
Control Mode
Settings
VF VFPG SVC FOCPG TQCPG FOCPM
0: no function ○ ○ ○ ○ ○ ○
1: multi-step speed command 1 ○ ○ ○ ○ ○
2: multi-step speed command 2 ○ ○ ○ ○ ○
3: multi-step speed command 3 ○ ○ ○ ○ ○
4: multi-step speed command 4 ○ ○ ○ ○ ○
5: Reset ○ ○ ○ ○ ○ ○
6: JOG command ○ ○ ○ ○ ○
7: acceleration/deceleration speed inhibit ○ ○ ○ ○ ○
8: the 1st, 2nd acceleration/deceleration time selection ○ ○ ○ ○ ○
9: the 3rd, 4th acceleration/deceleration time selection ○ ○ ○ ○ ○
10: EF input (07-28) ○ ○ ○ ○ ○ ○
11: Reserved
12: Stop output ○ ○ ○ ○ ○ ○
13: Disable auto accel./decel. function ○ ○ ○ ○ ○
14: Reserved
15: operation speed command form AUI1 ○ ○ ○ ○ ○
16: operation speed command form ACI ○ ○ ○ ○ ○
17: operation speed command form AUI2 ○ ○ ○ ○ ○
18: Emergency Stop (07-28) ○ ○ ○ ○ ○ ○
19-23: Reserved
24: FWD JOG command ○ ○ ○ ○ ○
25: REV JOG command ○ ○ ○ ○ ○
26: Reserved
27: ASR1/ASR2 selection ○ ○ ○ ○ ○
28: Emergency stop (EF1) (Motor coasts to stop) ○ ○ ○ ○ ○ ○
29-30: Reserved
31: High torque bias (by Pr.07-21) ○ ○ ○ ○ ○ ○
