Chapter 4 Parameters|
Revision Nov. 2008, VLE1, SW V1.03 4-17
Group 11 Advanced Parameters
Pr. Explanation Settings
Factory
Setting
VF
VF
PG
SVC
FOC
PG
TQC
PG
FOC
PM
11-00 System Control
Bit 0=0: no function
Bit 0=1: ASR Auto tuning, PDFF enable
Bit 7=0: no function
Bit 7=1: When position control is enabled, it doesn’t need to set
Pr.07-02 (DC Brake Current Level)
Bit 15=0: when power is applied, it will detect the position of
magnetic field again
Bit 15=1: when power is applied, it will start from the magnetic
field position of previous power failure 0 ○ ○
11-01 Elevator Speed 0.10~3.00 m/s 1.00 ○ ○
11-02 Sheave Diameter 100~2000 mm 400 ○ ○
11-03 Mechanical Gear Ratio 1~100 1 ○ ○
11-04 Suspension Ratio
0: 1:1
1: 2:1
1 ○ ○
11-05 Inertial Ratio 1~300% 40 ○ ○
11-06 Zero-speed Bandwidth 0~40Hz 10 ○ ○
11-07 Low-speed Bandwidth 0~40Hz 10 ○ ○
11-08 High-speed Bandwidth 0~40Hz 10 ○ ○
11-09 PDFF Gain Value 0~200% 30 ○ ○
11-10
Gain for Speed Feed
Forward
0~500 0 ○ ○
11-11 Notch Filter Depth 0~20db 0 ○ ○
11-12 Notch Filter Frequency 0.00~200.00Hz 0.00 ○ ○
11-13
Low-pass Filter Time of
Keypad Display
0.001~65.535s 0.500 ○ ○ ○ ○ ○ ○
11-14 Motor Current at Accel. 50~200% 150 ○
11-15 Elevator Acceleration 0.60~2.00m/s 0.75 ○
11-16 Reserved
11-17 Reserved
11-18 Reserved
