Chapter 4 parameters, Chapter 4 parameters -1 – Delta Electronics Elevator Drive VFD-VL User Manual
Page 56
Revision Nov. 2008, VLE1, SW V1.03
4-1
Chapter 4 Parameters
The VFD-VL parameters are divided into 14 groups by property for easy setting. In most
applications, the user can finish all parameter settings before start-up without the need for re-
adjustment during operation.
The 14 groups are as follows:
Group 0: System Parameters
Group 1: Basic Parameters
Group 2: Digital Input/Output Parameters
Group 3: Analog Input/Output Parameters
Group 4: Multi-Step Speed Parameters
Group 5: IM Motor Parameters
Group 6: Protection Parameters
Group 7: Special Parameters
Group 8: PM Motor Parameters
Group 9: Communication Parameters
Group 10: Speed Feedback Control Parameters
Group 11: Advanced Parameters
Group 12: User-defined Parameters
Group 13: View User-defined Parameters
