Chapter 4 Parameters|
4-4 Revision Nov. 2008, VLE1, SW V1.03
Group 1 Basic Parameters
Pr. Explanation Settings
Factory
Setting
VF
VF
PG
SVC
FOC
PG
TQC
PG
FOC
PM
01-00 Maximum Output Frequency 10.00~120.00Hz
60.00/
50.00
○ ○ ○ ○ ○ ○
01-01
1st Output Frequency
Setting 1
0.00~120.00Hz
60.00/
50.00
○ ○ ○ ○ ○ ○
01-02 1st Output Voltage Setting 1
230V: 0.1V~255.0V
460V: 0.1V~510.0V 220.0
440.0 ○ ○ ○ ○ ○ ○
01-03
2nd Output Frequency
Setting 1 0.00~120.00Hz 0.50 ○ ○
01-04
2nd Output Voltage Setting
1 230V: 0.1V~255.0V
460V: 0.1V~510.0V 5.0
10.0
○ ○
01-05
3rd Output Frequency
Setting 1 0.00~120.00Hz 0.50 ○ ○
01-06 3rd Output Voltage Setting 1
230V: 0.1V~255.0V
460V: 0.1V~510.0V 5.0
10.0
○ ○
01-07
4th Output Frequency
Setting 1 0.00~120.00Hz 0.00 ○ ○ ○ ○ ○
01-08 4th Output Voltage Setting 1
230V: 0.1V~255.0V
460V: 0.1V~510.0V 0.0
0.0 ○ ○
01-09 Start Frequency 0.00~120.00Hz 0.50 ○ ○ ○ ○
01-10
Output Frequency Upper
Limit
0.00~120.00Hz
120.00 ○ ○ ○ ○ ○
01-11
Output Frequency Lower
Limit
0.00~120.00Hz
0.00 ○ ○ ○ ○ ○
01-12 Accel Time 1
0.00~600.00 sec 3.00 ○ ○ ○ ○ ○
01-13 Decel Time 1
0.00~600.00 sec
2.00 ○ ○ ○ ○ ○
01-14 Accel Time 2
0.00~600.00 sec
3.00 ○ ○ ○ ○ ○
01-15 Decel Time 2
0.00~600.00 sec
2.00 ○ ○ ○ ○ ○
01-16 Accel Time 3
0.00~600.00 sec
3.00 ○ ○ ○ ○ ○
01-17 Decel Time 3
0.00~600.00 sec
2.00 ○ ○ ○ ○ ○
01-18 Accel Time 4
0.00~600.00 sec
3.00 ○ ○ ○ ○ ○
01-19 Decel Time 4
0.00~600.00 sec 2.00 ○ ○ ○ ○ ○
01-20 JOG Acceleration Time 0.00~600.00 sec
1.00 ○ ○ ○ ○ ○
01-21 JOG Deceleration Time 0.00~600.00 sec
1.00 ○ ○ ○ ○ ○
01-22 JOG Frequency
0.00~120.00Hz 6.00 ○ ○ ○ ○ ○ ○
01-23
Switch Frequency between
1st/4th Accel/decel 0.00~120.00Hz 0.00 ○ ○ ○ ○ ○
01-24
S-curve for Acceleration
Departure Time S1 0.00~25.00 sec 1.00 ○ ○ ○ ○ ○
01-25
S-curve for Acceleration
Arrival Time S2 0.00~25.00 sec 1.00 ○ ○ ○ ○ ○
01-26
S-curve for Deceleration
Departure Time S3 0.00~25.00 sec 1.00 ○ ○ ○ ○ ○
01-27
S-curve for Deceleration
Arrival Time S4 0.00~25.00 sec 1.00 ○ ○ ○ ○ ○
01-28
Mode Selection when
Frequency < Fmin
0: Output waiting
1: Zero-speed operation
2: Fmin (4th output frequency setting) 0 ○ ○ ○
01-29
Switch Frequency for S3/S4
Changes to S5 0.00~120.00Hz 0.00 ○ ○ ○ ○ ○
01-30
S-curve for Deceleration
Arrival Time S5 0.00~25.00 sec 1.00 ○ ○ ○ ○ ○
01-31
Deceleration Time when
Operating without RUN
Command 0.00~60.00 sec 2.00 ○ ○ ○ ○ ○
