Chapter 4 Parameters|
4-84 Revision Nov. 2008, VLE1, SW V1.03
08-03 Rated Speed of Motor (rpm) Unit: 1
Control
mode
FOCPM
Factory setting: 1710
Settings 0 to 65535
It is used to set the rated speed of the motor and need to set according to the value indicated
on the motor nameplate.
08-04 Number of Motor Poles
Control
mode
FOCPM
Factory setting: 4
Settings 2 to 96
It is used to set the number of motor poles (must be an even number).
08-05 Rs of Motor Unit: 0.001
Control
mode
FOCPM Factory setting: 0.000
Settings 0.000~65.535 Ω
08-06 Ld of Motor Unit: 0.1
Control
mode
FOCPM
Factory setting: 0.0
08-07 Lq of Motor Unit: 0.1
Control
mode
FOCPM
Factory setting: 0.0
Settings 0.0~6553.5mH
08-08 Reserved
08-09 Angle between Magnetic Field and PG Origin
Unit: 0.1
Control
mode
FOCPM
Factory setting: 360.0
Settings 0.0~360.0 °
This function is used to measure the angle between magnetic field and PG origin.
08-10
Magnetic Field Re-orientation
Control
mode
FOCPM
Factory setting: 0
Settings 0 Disable
1 Enable
