Chapter 4 Parameters|
Revision Nov. 2008, VLE1, SW V1.03 4-15
Group 9 Communication Parameters
Pr. Explanation Settings
Factory
Setting
VF
VF
PG
SVC
FOC
PG
TQC
PG
FOC
PM
09-00
Communication Address 1~254
1 ○ ○ ○ ○ ○ ○
09-01
Transmission Speed 4.8~115.2Kbps
9.6 ○ ○ ○ ○ ○ ○
09-02
Transmission Fault
Treatment 0: Warn and keep operation
1: Warn and ramp to stop
2: Reserved
3: No action and no display
3 ○ ○ ○ ○ ○ ○
09-03
Time-out Detection 0.0~100.0 sec
0.0 ○ ○ ○ ○ ○ ○
09-04
Communication Protocol 0: 7N1 (ASCII)
1: 7N2 (ASCII)
2: 7E1 (ASCII)
3: 7O1 (ASCII)
4: 7E2 (ASCII)
5: 7O2 (ASCII)
6: 8N1 (ASCII)
7: 8N2 (ASCII)
8: 8E1 (ASCII)
9: 8O1 (ASCII)
10: 8E2 (ASCII)
11: 8O2 (ASCII)
12: 8N1 (RTU)
13: 8N2 (RTU)
14: 8E1 (RTU)
15: 8O1 (RTU)
16: 8E2 (RTU)
17: 8O2 (RTU)
13 ○ ○ ○ ○ ○ ○
09-05 Response Delay Time
0.0~200.0ms 2.0 ○ ○ ○ ○ ○ ○
