Chapter 4 Parameters|
4-10 Revision Nov. 2008, VLE1, SW V1.03
Group 5 IM Motor Parameters
Pr. Explanation Settings
Factory
Setting
VF
VF
PG
SVC
FOC
PG
TQC
PG
FOC
PM
05-00 Motor Auto Tuning 0: No function
1: Rolling test (Rs, Rr, Lm, Lx, no-load current)
2: Static Test 0 ○
05-01 Full-load Current of Motor 40-120% #.## ○ ○ ○ ○ ○
05-02
Rated power of Motor 0.00~655.35kW #.## ○ ○ ○
05-03
Rated speed of Motor (rpm) 0~65535 1710 ○ ○ ○ ○
05-04 Number of Motor Poles 2~48 4 ○ ○ ○ ○ ○
05-05 No-load Current of Motor 0-100% #.## ○ ○ ○ ○
05-06 Rs of Motor 0.000~65.535 Ω 0.000 ○ ○ ○
05-07 Rr of Motor 0.000~65.535 Ω 0.000 ○ ○ ○
05-08 Lm of Motor 0.0~6553.5mH 0.0 ○ ○ ○
05-09 Lx of Motor 0.0~6553.5mH 0.0 ○ ○ ○
05-10
Torque Compensation Time
Constant 0.001~10.000sec 0.020 ○
05-11
Slip Compensation Time
Constant 0.001~10.000sec 0.100 ○
05-12 Torque Compensation Gain 0~10
0 ○ ○
05-13 Slip Compensation Gain 0.00~10.00
0.00 ○ ○ ○
05-14 Slip Deviation Level 0~1000% (0: disable)
0 ○ ○ ○
05-15
Detection Time of Slip
Deviation 0.0~10.0 sec 1.0 ○ ○ ○
05-16
Over Slip Treatment
0: Warn and keep operation
1: Warn and ramp to stop
2: Warn and coast to stop 0 ○ ○ ○
05-17 Hunting Gain
0~10000 (0: disable) 2000 ○ ○ ○
05-18 Accumulative Motor
Operation Time (Min.)
00~1439 00 ○ ○ ○ ○ ○
05-19 Accumulative Motor
Operation Time (day)
00~65535 00 ○ ○ ○ ○ ○
05-20
Core Loss Compensation 0~250% 10 ○
