Model 5820XL / 5820XL-EVS Installation Manual LS10061-001SK-E
6-13
6.6 Programming Menu Quick Reference
This section of the manual lists all Program Menu options in the order they appear on the sub-menus. Default
settings are indicated in text or marked with an asterisk (*). The comments column provide quick information
and a reference to a section (if applicable) which has more detailed information.
Table 6-1: Programming Quick Reference Table
Menu Options/Defaults(*) Comments
Module
Edit Module Select Module
Enter Module
ID
Enter Module Name
Edit Module
Settings (if
applicable)
Section 7.2.1
Add Module
5815XL-SLC
Section 7.2.2
5860 Keystat.
5824-Ser/Par/IO
5895XL Pwr Sup
5496 NAC Expand
5880-LED/IO Dev
5865-LED Annun.
EVS-50W
EVS-125W
EVS-INT50W
EVS-100W
EVS-VCM
EVS-RVM
Delete Module List of Module Section 7.2.3
View Module
List
List of Module Section 7.2.4
Zone Edit Zone Select Zone to Edit
Edit Zone Name Section 7.3.1.1
Section 7.3.1.2
Zone
Properties
Verification Type
*1 Count
2 Count
Alarm Ver.
PAS
SNGL ILOCK
DBL ILOCK
Heat Temp Set
135° to *150°F
SD devices Section
7.3.1.2
135° to 190°F,
*150°F SK devices Section
7.3.1.2
Zone Outputs
Manual Pull (MP) *Groups 01 &
250, (and 02 if
voice); Pattern
00
Section 7.3.1.3
Section 7.3.1.4
Water Flow (WF)
Detector Alarm (DE)
Aux 1 (A1)
*No Group Aux 2 (A2)
Pre-alarm (PR)
Fire Supervisory (SU)
*Group 249,
Pattern 00
Trouble (TR)
*No Groups
Status Point (SP)
