3.6.3 Current Draw Worksheet for SD SLC Devices
Use to determine current requirements during alarm/battery standby operation when SD SLC devices are
installed. You can install up SD devices per loop (Max per panel). Copy this section if additional space is
required.
Table 3-3: Current Draw Worksheet for SD SLC Devices
Device # of Devices Current per Device
Standby
Current
Alarm
Current
For each device use this formula: This column X This column = Current per number of devices.
IntelliKnight 5820XL Fire Panel (Current
draw from battery)
1
Standby: 275 mA 275 mA
Alarm: 440 mA 440 mA
Addressable SLC Devices
SD500-AIM
(508 max.) 1 Standby/Alarm: .55 mA 5
mA mA
SD500-MIM mA mA
SD500-PS mA mA
SD500-ARM mA mA
SD505-AHS mA mA
SD505-AIS mA mA
SD505-APS mA mA
SD500-ANM
(508 max.) 1
Aux. Pwr
Standby: 8 mA mA
Alarm: 60 mA mA
SLC Standby/Alarm: .55 mA mA mA
SD500-SDM
(508 max.) 1
SLC Standby/Alarm: .55 mA mA
Aux. Pwr
Standby: 20 mA mA
Alarm: 106 mA mA
SD500-LED
(100 max.) 1
Aux. Pwr
Standby: 10 mA mA
Alarm: 220 mA mA
LED: 10 mA mA mA
SLC Standby/Alarm: .55 mA mA mA
SLC Accessory Bases
SD505-6RB
(508 max.) Standby/Alram: .082 mA mA mA
SD505-6SB
(508 max.)
Aux. Pwr
Standby: 1 mA mA
Alarm: 32 mA mA
SLC Standby/Alarm .082 mA mA mA
SD505-DUCTR
(508 max.)
Aux. Pwr
Standby: 20 mA 2 mA
Alarm: 62 mA 2 mA
SLC Standby/Alarm: .5 mA mA mA
SD505-DTS-K (508 max.) None, included with SD505-DUCTR worst case.
SD505-DUCT (508 max.) None, included with detector current.
SLC Isolator Devices
SD500-LIM
(1024 max.)
Standby/Alarm .092 mA
mA mA
SD505-6IB (508 max.)
Accessories Modules
5815XL SLC Expander
(3 max.) Standby/Alarm: 55 mA mA mA
5860 Remote Fire Alarm Annunciator.
*EVS-RCU contains one 5860 and must
be added to the calculation here.”.
(12 max.)
Standby: 20 mA mA
Alarm: 25 mA
mA
5824 Serial/Parallel Printer Interface (2 max.) Standby/Alarm: 45 mA mA mA
5895XL IntelliKnight Power Expander
(8 max.)
Standby/Alarm: 10 mA mA mA
5496 Intelligent Power Module Standby/Alarm: 10 mA mA mA
5865-4 LED Annunciator
(with reset and silence switches)
(8 max.)
Standby: 35 mA mA
Alarm: 145 mA mA
5865-3 LED Annunciator Standby: 35 mA mA
Alarm: 145 mA mA
5880 LED I/O Module Standby: 35 mA mA
Alarm: 200 mA mA
