SilentKnight 5820XL User Manual

Page 125

Model 5820XL / 5820XL-EVS Installation Manual

LS10061-001SK-E

7-17

SLC Loop

SWITCH

(cont.)

SYSTEM AUX1

Latching

Use these switch types if you want to monitor special
system-wide conditions (such as operation of a fan or
damper).

Non Latching

SYSTEM AUX2

Latching

Non Latching

DETECTOR SW

Used to monitor conventional 4-wire detectors, a contact
closure will generate a detector alarm event.

TAMPER

Latching

Performs identically to a supervisory switch, but will be
indicated as a tamper switch on the LCD annunciator.

Non Latching

MANUAL RELEASE

Latching

Non Latching

Manual release switch, typically a pull station.

INTERLOCK

Interlock release switch input.

CO DETECTOR
STATUS PT

Status Point

Switch

CO Detector Switch

NOTIF

OUTPUT PT

Select Group

Output point, a general use notification type. Use for
driving standard notification appliances.

AUX CONST

Use constant power for applications that require a
constant auxiliary power source. Power is always
present at constant circuits.

AUX RESET

Use for auxiliary power, resettable applications. See
Section 4.12.5.3 for a description of how this option
operates.

AUX DOOR

Use for auxiliary power, door holder applications. For
example, if you were using an auxiliary power supply for
door holders, you would use this option. See Section
4.12.5.1 for a description of how this option operates.

RELAY

OUTPUT PT

Select Group

Output point, a general use relay type. Use for
applications requiring a relay, such as fan shutdown,
elevator recall, and so on.

AUX RESET

Select Group

Use for auxiliary power, resettable applications. See
Section 4.12.5.3 for a description of how this option
operates.

AUX DOOR

Select Group

SD SLC LED

Select LED No.
01 -80

Select Group

Table 7-5: Point Programming Options for 5815XL Modules

Module Type

Type

Selection

Function

Latching

Option

Comments
