Model 5820XL / 5820XL-EVS Installation Manual
10-7
External Reset/Silence/Fire Drill
switch trouble Trouble pi Exp. ID UT Point # 1 373 Exp. ID Point #
External Reset/Silence/Fire Drill
switch trouble restore Trouble pi Exp. ID UJ Point # 3 373 Exp. ID Point #
External Reset/Silence/Fire Drill
Switch Disabled Disable pi Exp. ID UB Point # 1 571 Exp. ID Point #
External Reset/Silence/Fire Drill
Switch Enabled Disable pi Exp. ID UU Point # 3 571 Exp. ID Point #
LOC Emergency # Alarm 1 Alarm pi Exp. ID QA Emergency # 1 220 +
Emer-
gency # Exp. ID Emergency #
LOC Emergency # Alarm Restore 1 Restore pi Exp. ID QH Emergency # 3 220 +
Emer-
gency # Exp. ID Emergency #
Manual Pull switch alarm Alarm pi Exp. ID FA Point # 1 115 Exp. ID Point #
Manual Release switch alarm (Water
Release Zone) Alarm pi Exp. ID FA Point # 1 110 Exp. ID Point #
Interlock Switch alarm (Water
Release Zone) Alarm pi Exp. ID FA Point # 1 110 Exp. ID Point #
Point Disabled Disable pi Exp. ID FB Point # 1 571 Exp. ID Point #
Manual Pull switch alarm restore Restore pi Exp. ID FH Point # 3 115 Exp. ID Point #
Manual Release switch alarm restore
(Water Release Zone) Restore pi Exp. ID FH Point # 3 110 Exp. ID Point #
Interlock Switch alarm restore (Water
Release Zone) Restore pi Exp. ID FH Point # 3 110 Exp. ID Point #
Notification Output trouble restore Trouble pi Exp. ID FJ Point # 3 320 Exp. ID Point #
Manual Pull switch trouble restore Trouble pi Exp. ID FJ Point # 3 373 Exp. ID Point #
Manual Release switch trouble
restore (Water Release Zone) Trouble pi Exp. ID FJ Point # 3 373 Exp. ID Point #
Interlock Switch trouble restore
(Water Release Zone) Trouble pi Exp. ID FJ Point # 3 373 Exp. ID Point #
Positive Alarm Sequence
acknowledge switch trouble restore Trouble pi Exp. ID FJ Point # 3 373 Exp. ID Point #
Notification Output trouble Trouble pi Exp. ID FT Point # 1 320 Exp. ID Point #
Manual Pull switch trouble Trouble pi Exp. ID FT Point # 1 373 Exp. ID Point #
Manual Release switch trouble
(Water Release Zone) Trouble pi Exp. ID FT Point # 1 373 Exp. ID Point #
Interlock Switch trouble (Water
Release Zone) Trouble pi Exp. ID FT Point # 1 373 Exp. ID Point #
Positive Alarm sequence
acknowledge switch trouble Trouble pi Exp. ID FT Point # 1 373 Exp. ID Point #
Point Enabled Disable pi Exp. ID FU Point # 3 571 Exp. ID Pnt #
Status Point Trouble Trouble pi Exp. ID UT Point # 1 379 Exp. ID Point #
Status Point Trouble Restored Trouble pi Exp. ID UJ Point # 3 379 Exp. ID Point #
Status Point is Disabled Disable pi Exp. ID UB Point # 1 580 Exp. ID Point #
Status Point is Enabled Disable pi Exp. ID UU Point # 3 580 Exp. ID Point #
Supervisory/Tamper switch or
supervisory detector disabled Disable pi Exp. ID FB Point # 1 571 Exp. ID Point #
SIA Reporting Format Contact ID Reporting Format
Event Description
Event
Family
Module
ID #
(if any)
SIA
Event
Code
Parameter (if
any)
Qualifier
Event
Code
Group
#
Contact
#
