Model 5820XL / 5820XL-EVS Installation Manual LS10061-001SK-E
9-11
9.8.4 View Active Alarms, Troubles and Supervisory Signals
When looking at the LCD display, the screen will display FS for the “Fire System” and EVS for “Emergency
Voice System” after the condition. The highest priority event will display first. (See Figure 9-5). Press the down
arrow to view location and type of alarm or trouble. After sitting idle for two minutes, events will display on line
4 of display. (See Figure 9-6).
Figure 9-5 Highest Priority Event Display
Figure 9-6 Event Screen After Two Minutes Sitting Idle
9.9 Using the Microphone
9.9.1 Microphone Functionality
Each microphone in the system is capable of providing live fire system or EVS paging.
The microphones are housed within the EVS-Series panel enclosure and the EVS-RCU cabinets. A maximum of
8 microphones can be installed in the system.
9.9.2 Custom EVS Event
This event is activated by gaining EVS control at an LOC and using the microphone without any EVS event
already active. In this case, the custom EVS mapping and general EVS mapping will be activated and stay
activated until a different EVS event is activated at the LOC or the user resets the Emergency Voice System.
EVS System Fire System
Count of alarms/troubles
currently active
CO Alarm
EVS System
Fire System
