SilentKnight 5820XL - Manual (Page 90)

Model 5820XL / 5820XL-EVS Installation Manual LS10061-001SK-E
6-11
6.5.1.1 Moving through the Menus
Figure 6-8 shows how to move through Program Menu screens, using the System Options screen as an example.
Figure 6-8 Moving through Program Menu
6.5.1.2 Selecting Options and Entering Data
There are several ways to make programming selections using the control panel depending on which screen you
are currently viewing. The chart below is a generic explanation.
To Press
Enter the number The corresponding number on the annunciator.
Enter numeric data The appropriate number on the annunciator.
Enter text (alphanumeric data)
Enter each character individually by using the or arrow keys until the one
you wish to select displays. Then press the right arrow to select the character.
Select from a scrolling list
T he or arrow keys to move through the list of available options. When the
option you want to select is displayed, press ENTER.
