Model 5820XL / 5820XL-EVS Installation Manual LS10061-001SK-E
7-11
7.4.1.2 Edit Group Properties
1. Follow steps 1-5 of section 7.4.1
2. To edit the group properties, press 2.
The Edit Group Menu allows you to select options for each group for the following items:
• Latching or non-latching outputs.
• Silencing operation.
• Reverse Polarity options.
• Operation with system switches.
• Define output group type as voice or non-voice and Allow Override. These options are for EVS Only. See
Figure 7-9.
Figure 7-9 Group Properties Screen Programming Options
Latching / Non-latching Outputs
Outputs that are programmed as Latching remain active until the system has been manually reset. Non-latching
outputs stop activating automatically when the condition clears.
Silencing Options
The following silencing options are available for each output group.
Table 7-2: Silencing Options
Option Description
SILENCE Silenceable. The output group can be silenced through the SILENCE key.
NON-SIL Not silenceable. The output group cannot be silenced. Activation of the SILENCE key will be ignored for this
output group.
AUT UNSIL Auto Unsilenced. If this option is selected, the output group can be silenced for a programmed time-frame. If
the condition that caused the output to activate has not cleared during the time-frame, the output reactivates.
If you select this option, select the time-frame in the delay field. Range is 05-60 minutes. (See Figure 7-9 for
location of field.)
SIL-INHIB Timed Silence after Inhibit. If this option is selected, the output group must be audible for a programmed
number of minutes before it can be silenced. If the condition that caused the output to activate has not cleared
during the time-frame, the output can be silenced. If you select this option, select the timeframe in the delay
field. Range is 05-60 minutes. (See Figure 7-9 for location of field.)
SHUT-DOWN If this option is selected, the output group will automatically silence (shut down) after the programmed time
period. If you select this option, select the timeframe in the DLY: field. Range is 01-60 minutes. (See Figure 7-
9 for location of field.)
