Model 5820XL / 5820XL-EVS Installation Manual LS10061-001SK-E
8-9
8.5.18 Working with a Printer
If you are using the Model 5824 serial/parallel interface module, several printing options are available. See
Section 4.7 for information about installing the 5824.
1. From the Main Menu, select 5 Printer Options.
2. From the next screen, select the 5824 module where the printer is connected.
3. If the printer is not currently busy printing another report, a screen with the following options will be avail-
able. If the printer is busy, a message will display. You can press 1 to cancel the current print job. These
options will then display.
1= Event Logging Enables event logging, which causes the printer to continuously print events as they occur. The
date/time will print in 24-hour military format. Once event logging is enabled, it will remain enabled
until canceled by the installer. If you need to disable event logging, return to this option and press
1 to disable.
Sample Event Log
2 = Print Event History Prints the up-to-1000 events currently stored in the panel’s event history buffer. Events print
starting with the newest. The date and time printed will be when the event actually occurred and
will print in 24-hour military format.
Sample Event History
Print-Out
3 = Print Detector Status Prints the current status of all detectors in the system. This is a method for finding out if any
detectors are out of NFPA compliance or any detectors need maintenance (are approaching an
out of compliance condition).
Sample Detector Status
Print-Out
Note: Detector status can also be viewed and printed using the 5660 SKSS
4 = Print System Cfg
Prints the current system configuration of the panel. The entire configuration can be printed, or just
specific sections.
EVENT LOG:
EVENT LOG:
STARTED: 02/17/97 02:23
STOPPED: 02/17/97 15:02
02/17/97 11:23 Event: System Silenced
02/17/97 11:24 Event: System Reset
02/17/97 14:30 Event: Local Programming Begin
02/17/97 15:01 Event: Local Programming Ended Successfully
EVENT HISTORY: PRINTED: 02/28/97 13:35
02/20/97 09:05 Event 2 of 10: System Reset
02/28/97 13:31 Event 2 of 10: Walk Test End
02/20/97 09:02 Event 3 of 10: System Silenced
02/22/97 08:47 Event 4 of 10: Printer Off Line 4
02/22/97 08:52 Event 4 of 10: Printer On Line 4
02/25/97 15:54 Event 5 of 10: Local Programming Begin
02/25/97 16:10 Event 5 of 10: Local Programming Ended Successfully
02/28/97 12:50 Event 6 of 10: Walk Test Begin
.
.
.
