LS10061-001SK-E System Operation
8-16
8.7.1 Single Interlock Zone Releasing
A single interlock zone utilizes a minimum of two addressable detectors and a designated manual release switch.
Conditions Required for an Pre-Alarm Output Activation
If any single addressable detector is activated, the “Pre-Alarm” output will activate. This alerts the user that the
initial stages required for a release condition are present. (Also refer to Table 8-3.)
Conditions required for an General Alarm and Release Output Activation
If two or more addressable detectors, or a manual release switch activate, the “Alarm” and the “Release” outputs
will activate and the “Pre-Alarm” output will deactivate. (Also refer to Table 8-3.)
Important!
Only addressable detectors can be used. No conventional detectors can be used.
Each Single Interlock Zone input requires at least one manual release switch.
Table 8-3: Single Interlock Zone Operation
Inputs Output Results
1st Addressable Detector x x x x
2nd Addressable Detector x x x x
Manual Release Station x x x x
Nor
m
al
Pre-Alarm Pre-Alarm
Rele
ase and
Gen
e
ra
l Alarm
Rele
ase and
Gen
e
ra
l Alarm
Rele
ase and
Gen
e
ra
l Alarm
Rele
ase and
Gen
e
ra
l Alarm
Rele
ase and
Gen
e
ra
l Alarm
