Model 5820XL / 5820XL-EVS Installation Manual LS10061-001SK-E
7-21
10. Press the or arrows to select the function.
11. Press ENTER.
12. Use the or arrows to modify and remaining options and use ENTER to move to the next field.
13. Edit module name. See Section 7.2.1.1. or, Press the right arrow to skip module name edit.
14. Repeat Steps 1 through 13 for all points.
7.5.5 Assigning a Name to Points
You can assign a name to a point to make it easier to recognize on a display.
To edit a point name:
1. When the display is flashing on the Edit Name field press ENTER.
2. Use the or arrow to scroll through the character options. Refer to Appendix B.
3. Use the number keys to select desired characters.
4. Use the LEFT or RIGHT arrows to change character position.
5. Press ENTER when finished. If you wish to bypass the Edit Name field press the right arrow.
Table 7-7: Point Programming Options for EVS-VCM and EVS-RVM
Choices Type Selections
Function Selections
for each Type
Comments
Select Type
UNUSED
SWITCH
MANUAL PULL
Refer to comments column of
Table 7-6 for description of
these options. Latch or Non-
latching feature only appears for
waterflow, supervisory, tamper,
zone aux1, zone aux2, system
aux1, and system aux2.
WATERFLOW
FIRE SUPERVISORY
TAMPER
FIREDRILL
SILENCE
RESET
PAS_ACK
ZONE AUX1
ZONE AUX2
SYSTEM AUX1
SYSTEM AUX2
MANUAL RELEASE
INTERLOCK
STATUS POINT
V_AuxStat No Alarm LED
V_AuxECS General Alarm LED
