SilentKnight 5820XL - Manual (Page 143)

Model 5820XL / 5820XL-EVS Installation Manual LS10061-001SK-E
7-35
7.9.1 Profile Edit Menu
From the Profile Edit Menu you can change the users name, access code, and the panel functions that the user
will have access to with their code.
Note: Profile 1 (Fire Fighter’s Key) the user name and access code can not be edited. Profile 2 (Installer) the
user name and panel functions can not be edited.
7.9.1.1 Edit Name
6. Select each character of a word by pressing the or arrow, then press the right arrow to move to the
next character.
7. Repeat step 6 until user name is complete.
8. Then press ENTER to finish.
7.9.1.2 Edit Access Code
9. Enter new access code (minimum of 4 digits, maximum of 7 digit).
10. Press ENTER.
11. Enter code again.
12. Press ENTER.
7.9.1.3 Panel Functions
13. Press the or arrow to move through the list of available functions.
14. Then press the right arrow to move to Y (yes) or N (no) selection column.
15. Press the or arrow to select Y or N.
16. Press ENTER.
17. Repeat steps 13 through 16 until user profile is complete.
7.10 Voice Options
7.10.1 EVS-VCM Maintenance
The EVS-VCM Maintenance menu is used to program custom messages into the EVS-VCM. Messages.
1. Enter the installer code. The panel will automatically go to the main menu.
2. Select 7 for Program Menu.
3. Select 9 for Voice Options.
4. Select 1 for VCM Maintenance.
7.10.1.1 PC Connection
This option is used when adding or editing user message through the EVS Message Manager Software. Refer to
Section 9.10.4 for more information on this procedure.
7.10.1.2 Local Recording
Select this option if you wish to record the user message with the EVS-VCM microphone, or through the sound
card of your PC. Refer to Section 9.10.1 and Section 9.10.2 for more information on this procedure.
7.10.2 Edit Voice Commands
When a voice output group is selected to be activated by a zone, the cadence pattern choice listed in Section
