Model 5820XL/5820XL-EVS Installation Manual

LS10061-001SK-E

11-5

11.5.3

I/O Point Control

This feature allows you to toggle any output on or off and trip any input device. This can be useful to test a
point’s output mapping.

Follow these steps to control a I/O point:

1.

Select 2 (Point Functions) from the Main Menu.

2.

Select 6 (I/O Point Control).

3.

Select the module the point is on.

4.

Use the

or

arrow to select the point you wish to test.

5.

Press ENTER to generate an alarm for an input point or activate an output point.

6.

To exit press the left arrow.
