Before You Begin Installation
3-2
3.3
Electrical Specifications
Table 3-1: Terminal Descriptions and Electrical Specification
Terminal # and Label
Description
Rating
Earth Ground
Faults
Voltage
Current
1
L
AC input (hot)
120 VAC, 60 Hz
2.7 A
N/A
2
Earth ground
N/A
N/A
N/A
3
N
AC input (neutral)
120 VAC, 60 Hz
2.7 A
N/A
4
X
*I/O 6
Flexput™ Circuits
24 VDC
3.0A notification and auxiliary
power circuits
0
5
O
100 mA for initiation circuits
6
X
*I/O 5
Flexput™ Circuits
24 VDC
3.0A notification and auxiliary
power circuits
0
7
O
100 mA for initiation circuits
8
X
*I/O 4
Flexput™ Circuits
24 VDC
3.0A notification and auxiliary
power circuits
0
9
O
100 mA for initiation circuits
10
X
*I/O 3
Flexput™ Circuits
24 VDC
3.0A notification and auxiliary
power circuits
0
11
O
100 mA for initiation circuits
12
X
*I/O 2
Flexput™ Circuits
24 VDC
3.0A notification and auxiliary
power circuits
0
13
O
100 mA for initiation circuits
14
X
*I/O 1
Flexput™ Circuits
24 VDC
3.0A notification and auxiliary
power circuits
0
15
O
100 mA for initiation circuits
16
B
SBUS OUT
SBUS communication
5 VDC
100 mA
0
17
A
18
+
SBUS power
24 VDC
1.0 A
19
-
20
B
SBUS IN
Used for Class A installations
0
21
A
22
+
23
-
24
N.C.
RELAY 1
General Purpose Relay 1
24 VDC
2.5 A, resistive
N/A
25
C
26
N.O.
27
N.C.
RELAY 2
General Purpose Relay 2
24 VDC
2.5 A, resistive
N/A
28
C
29
N.O.
30
N.C.
TROUBLE
Trouble Relay
24 VDC
2.5 A, resistive
N/A
31
C
32
N.O.
33
SC-
L1
SLC OUT
SLC terminals
32 VDC
150 mA
0
34
SC+
* Regulated for NAC circuits, special applications when used for releasing or auxiliary power circuits
