LS10061-001SK-E
7-1
Section 7
Programming
This section of the manual describes how to manually program the control panel from the built-in annunciator.
Each subsection discusses these menu options in detail. All options described in this section can be performed
using 5660 Silent Knight Software Suite (SKSS).
7.1
UL 864 / UL 2572 Programming Requirements
7.2
Modules
This section lists the options available under the module option in the program menu. The following modules are
available for the control panel: 5815XL SLC expander, 5860 remote fire alarm annunciator, 5824 serial/parallel
printer interface module, 5496 intelligent power module, 5895XL intelligent power module, 5880 LED I/O
module, and 5865 LED annunciator, EVS-50W, EVS-INT50W, EVS-100W or EVS-125W audio/voice
amplifiers, EVS-VCM voice control module, and EVS-RVM remote voice module.
Important!
Before any customized programming is done, JumpStart should be run first. After JumpStart is run,
thoroughly test the system. The reason the system should be tested after JumpStart is because JumpStart
automatically programs the system, searching for and configuring all SLC and SBUS devices it finds.
JumpStart allows you to confirm the integrity of the installation prior to performing any custom
programming. After determining that the hardware is properly installed, custom programming can be
performed. Refer to Section 6.
NOTICE TO USERS, INSTALLERS, AUTHORITIES HAVING JURISDICTION, AND OTHER INVOLVED
PARTIES: This product incorporates field programmable software. In order for the product to comply with the
requirements in the Standard for Control Units and Accessories for Fire Alarm Systems, UL 864 and UL 2572,
certain programming features or options must be limited to specific values or not used at all as indicated below.
Programming
Option
Menu Item
Permitted
in
UL 864
(Y/N)
Permitted
in
UL 2572
(Y/N)
Possible
Settings
Settings
Permitted
in
UL 864
Settings
Permitted
in
UL 2572
Time Options
Low AC Report Delay Yes
Yes
0–30 hours
1–3
1–3
Display Oldest Event
Y (Enabled)
Yes
Yes
Yes & No
Yes
Yes
N (Disabled)
No
No
Yes & No
No
No
Initial Delay
0-28
Yes
Yes
0-28
3-10
4-28
Inter Message Delay
4-32
No
No
4-32
4-32
4-28
Alarm Verification
Alarm Verification
Yes
Yes
1-250
1-60
1-60
Auto Reset
EVS Custom Event
Auto Reset EVS
Custom Event
Yes
Yes
Never
Timer Event
Disabled
Never
Timer Event
Disabled
Never
Timer Event
Disabled
EVS Input
EVS Input
Yes
Yes
Latching
Non-Latching
Latching
Latching
