Appendix
C
PowerFlex 700S Hi-Resolution (Stegmann)
Encoder Feedback Option
Specifications Hi-Resolution (Stegmann) Feedback Option Card Specifications
Supported Encoders
Table C.A specifies which encoders are supported by the 700S
Hi-Resolution Stegmann Encoder Feedback Option module.
Important: Please note that encoders must be ordered as "Single Ended".
This will ensure that the RS-485 channel has the proper
termination network installed at the factory.
Table C.A Supported Stegmann Encoders
Consideration Description
Encoder Voltage Supply 11.5V dc @ 130 mA
Stegmann Feedback Sine/Cosine 1V P-P Offset 2.5
Maximum Cable Length 90m (295 ft)
Maximum Frequency
(Encoder Speed) 12.5
μ
s/cycle
(4687.5 RPM for encoders with 1024 sine cycles per revolution)
(9375 RPM for encoders with 512 sine cycles per revolution)
RS-485 Interface The Hi-Resolution Feedback Option card obtains the following
information via the Hiperface RS-485 interface shortly after
power-up:
•
Address
•
Command Number
•
Mode
•
Number of turns
•
Number of Sine/Cos cycles
•
Checksum
Customer-I/O plug (P1) Allen-Bradley PN: S94262912
Weidmuller PN: BL3.50/90/12BK
Model Resolution Comment
SINCOS® SCS-60, SCS-70,
SCM-60, and SCM-70 512 sine cycles per revolution. SCM-60 and SCM-70 have built-in
mechanical turns counter.
SINCOS® SCS-KIT-101 and
SCM-KIT-101 1024 sine cycles per revolution. SCM-60 and SCM-70 have built-in
mechanical turns counter.
SINCOS® SRS-50, SRS-60,
SRM-50, and SRM-60 1024 sine cycles per revolution. SRM-50 and SRM-60 have built-in
mechanical turns counter.
SINCOS
®
SRS/M 25 1024 sine cycles per revolution SRS25 and SRM25 have built-in
mechanical turns counter. IP65
Protection Class. Size 25 square
flange mounting.
