Overview

p-3

The following manuals are recommended for detailed installation and
service information for PowerFlex 700H and 700S drives:

For Allen-Bradley Drives Technical Support:

Manual Conventions

In this manual we refer to the PowerFlex 700H or 700S Adjustable
Frequency AC Drive as:

drive

PowerFlex 700H

700H

PowerFlex 700S

700S

To help differentiate parameter names and LCD display text from other
text, the following conventions will be used:

Parameter Names will appear in [brackets].

For example: [DC Bus Voltage].

Display Text will appear in “quotes.” For example: “Enabled.”

The following words are used throughout the manual to describe an
action:

Title

Publication

Installation Instructions - PowerFlex 700H/S IP00 Open Pwr Structure - Frm 10-13 PFLEX-IN020…
Hardware Service Manual - PowerFlex 700S and 700H Drives (Frame 9)

PFLEX-TG001…

Hardware Service Manual - PowerFlex 700S and 700H Drives (Frame 10)

PFLEX-TG002…

Hardware Service Manual - PowerFlex 700S and 700H Drives (Frame 11)

PFLEX-TG003…

Hardware Service Manual - PowerFlex 700S and 700H Drives (Frame 12)

PFLEX-TG004…

Hardware Service Manual - PowerFlex 700S and 700H Drives (Frame 13)

PFLEX-TG005…

Hardware Service Manual - PowerFlex 700S and 700H Drives (Frame 14)

(not yet available)

Title

Online at . . .

Allen-Bradley Drives Technical Support

www.ab.com/support/abdrives

Word

Meaning

Can

Possible, able to do something

Cannot

Not possible, not able to do
something

May

Permitted, allowed

Must

Unavoidable, you must do this

Shall

Required and necessary

Should

Recommended

Should Not

Not recommended
