Frame 14 Installation
11-23
Figure 11.11 Drives Above 1500A Terminal Locations
U/T1
V/T2
W/T3
L3
L1
L2
L3
L1
L2
U/T1
V/T2
W/T3
Side View
Ground Terminals
DC Bus Terminals
(In Both Enclosures)
Output Power Terminals
without du/dt Filters
(in two center enclosures)
Output Power Terminals
with du/dt Filters
(in two center enclosures)
DC–
(Front Terminals)
DC+
(Back Terminals)
➊
➍
➌
➋
➋
Input Power
Terminals
➊
Input Power
Terminals
Center Enclosures Shown
