ii

Summary of Changes

The information below summarizes the changes to the PowerFlex 700H and
700S Installation Instructions
, publication PFLEX-IN006, since the
October, 2004 release.

Change

Page

Updated the drive ratings for PowerFlex 700H and 700S

Preface-1

Updated the information on installing unbalanced, ungrounded or resistive grounded
distribution systems

1-1

Added information on DC input precharge control wiring

1-10

Updated the “Control Board Slot Designations” table for the new 20C-DG1 digital I/O
option board

2-2

Added drive catalog numbers for 700H control I/O board options

2-2

Updated the “Analog Input, PTC 0-10V Input” wiring example

2-8

Added Chapter 4, “Control Wiring for PowerFlex 700S Drives with Series II Control”

4-1

Updated information on frame 9 operating temperatures

6-2

Updated frame 9 installation instructions for unbalanced, ungrounded or resistive
grounded distribution systems

6-4

Updated frame 10 minimum mounting clearances

7-1

Updated frame 10 operating temperatures

7-2

Added dimensions drawing for frame 10 NEMA/UL Type 12 - IP54 Enclosure

7-5

Updated frame 10 “Moving Control Frame” to show slotted holes in Control Frame

7-6

Updated frame 10 “Removing Protective Covers” to omit screws that were not present.

7-8

Updated frame 10 installation instructions for unbalanced, ungrounded or resistive
grounded distribution systems

7-9

Updated frame 11 minimum mounting clearances

8-1

Updated frame 11 operating temperatures

8-2

Added dimensions drawing for frame 11 NEMA/UL Type 12 - IP54 Enclosure

8-5

Updated frame 11 installation instructions for unbalanced, ungrounded or resistive
grounded distribution systems

8-9

Added Chapter 9, “Frame 12 Installation”

9-1

Added Chapter 10, “Frame 13 Installation”

10-1

Updated the agency certifications

A-1

Updated the drive protection specifications

A-1

Updated the fusing and circuit breaker specifications

A-13

,

A-13

Added specifications and wiring diagram for using the Stahltronic linear encoder

E-3
