Rockwell Automation 20D PowerFlex 700H and 700S Frame 9-14 Drives Installation - A4 Size User Manual
Page 142
10-10
Frame 13 Installation
Removing the Protective
Covers from the Inverter
Unit
Removing the Lower Protective Screen
To access the power terminals, you must first remove the lower protective
screen (on NEMA/UL Type 1 and Type 12 enclosures).
Task
Description
Remove the screws that secure the lower protective screen to the right side
enclosure only and remove the screen.
A
A
