Page 72

5-2
Communication Options
Communication
Configurations
Typical Programmable Controller Configurations
Important: If block transfers are programmed to continuously write
information to the drive, care must be taken to properly format
the block transfer. If attribute 10 is selected for the block
transfer, values will be written only to RAM and will not be
saved by the drive. This is the preferred attribute for continuous
transfers. If attribute 9 is selected, each program scan will
complete a write to the drives non-volatile memory (EEprom).
Since the EEprom has a fixed number of allowed writes,
continuous block transfers will quickly damage the EEprom.
Do Not assign attribute 9 to continuous block transfers. Refer to
the individual communications adapter User Manual for details.
Logic Command/Status Words
Figure 5.2 PowerFlex 700H Logic Command Word
Logic Bits
15 14 13 12 11 10 9
8
7
6
5
4
3
2
1
0
Command
Description
x
Stop
0 = Not Stop
1 = Stop
x
Start
(1)(2)
(1)
A “0 = Not Stop” condition (logic 0) must first be present before a “1 = Start” condition will start the drive. The
Start command acts as a momentary Start command. A “1” will start the drive, but returning to “0” will not stop
the drive.
(2)
This Start will not function if a digital input (Pars 361-366) is programmed for 2-Wire Control (option 7, 8 or 9).
0 = Not Start
1 = Start
x
Jog
0 = Not Jog
1 = Jog
x
Clear Faults 0 = Not Clear Faults
1 = Clear Faults
x
x
Direction
00 = No Command
01 = Forward Command
10 = Reverse Command
11 = Hold Present Direction
x
Local
Control
0 = No Local Control
1 = Local Control
x
MOP
Increment
0 = Not Increment
1 = Increment
x
x
Accel Rate
00 = No Command
01 = Use Accel Time 1
10 = Use Accel Time 2
11 = Use Present Time
x
x
Decel Rate
00 = No Command
01 = Use Decel Time 1
10 = Use Decel Time 2
11 = Use Present Time
x
x
x
Reference
Select
(3)
(3)
This Reference Select will not function if a digital input (Pars. 361-366) is programmed for “Speed Sel 1, 2 or 3”
(option 15, 16 or 17). Note that Reference Selection is “Exclusive Ownership.”
000 = No Command
001 = Ref. 1 (Ref A Select)
010 = Ref. 2 (Ref B Select)
011 = Ref. 3 (Preset 3)
100 = Ref. 4 (Preset 4)
101 = Ref. 5 (Preset 5)
110 = Ref. 6 (Preset 6)
111 = Ref. 7 (Preset 7)
x
MOP
Decrement
0 = Not Decrement
1 = Decrement
