PowerFlex 700S Hi-Resolution (Stegmann) Encoder Feedback Option C-3
Recommended Cables
If you are using this motor and feedback
device:
Use this cable: See this wiring diagram:
Allen-Bradley 1326AB-BXXXX-21ML, and
-21MKXL motors with embedded Stegmann
rotary encoder Allen-Bradley 1326-CECU-XXL-XXX Figure C.1 on page C-4
Allen-Bradley 1326AB-BXXXX-M2L, -M2KXL,
-S2L, and -S2KXL motors with embedded
Stegmann rotary encoder Allen-Bradley 2090-CDNFDMP-SXX Figure C.2 on page C-4
Allen-Bradley MPL-A5xx and all MPL-Bxxx
motors with embedded Stegmann rotary
encoder Allen-Bradley 2090-CDNFDMP-SXX Figure C.2 on page C-4
Allen-Bradley 1326AB-BXXXX-M2L, -M2KXL,
-S2L, and -S2KXL motors with embedded
Stegmann rotary encoder Allen-Bradley 2090-XXNFMP-SXX Figure C.3 on page C-4
Allen-Bradley MPL-A5xx and all MPL-Bxxx
motors with embedded Stegmann rotary
encoder Allen-Bradley 2090-XXNFMP-SXX Figure C.3 on page C-4
Allen-Bradley MPL-A3xx - MPL-A45xx and all
MPG series motors with embedded
Stegmann rotary encoder Allen-Bradley 2090-XXNFMP-SXX Figure C.4 on page C-5
Allen-Bradley MPL-A3xx - MPL-A45xx and all
MPG series motors with embedded
Stegmann rotary encoder Allen-Bradley 2090-UXNFDMP-SXX Figure C.5 on page C-5
Any other motor with external Stegmann
SHS-170 rotary encoder Stegmann shielded twisted-pair cable with 12-pin DIN style connector Figure C.6 on page C-5
Any other motor with external Stegmann
SCS-60, SCS-70, SCM-60 or SCM-70,
SRS-50, SRS-60, SRM-60, SRM-60,
SRS-25, SRM-25 or Allen-Bradley 842HR
rotary encoder Stegmann shielded twisted-pair cable with 10-pin MS style connector Figure C.7 on page C-6
Any other motor with external Stegmann
SCS-Kit 101 or SCK-Kit 101 rotary encoder Stegmann shielded twisted-pair cable with 8-pin Berg style connector Figure C.8 on page C-6
Any other motor with external Stegmann
SRS660 rotary encoder Is available only with pre-attached Stegmann shielded twisted-pair
cable of various lengths Figure C.9 on page C-6
