Preface

Overview

Drive Description

Frame 9 - 14 PowerFlex® 700H and 700S AC drives are available in the
following normal duty power ratings.

The 700H features a parameter set modeled after the PowerFlex 700 AC
drive. Standard I/O includes either 24V or 115V digital I/O plus analog I/O
NetLinx™ communication options, including DeviceNet™, ControlNet™
and EtherNet/IP networks.

The PowerFlex 700S offers optimized integration for the most demanding
drive control and drive system applications. Available with embedded
high-performance Logix engine (DriveLogix) to produce a highly
functional, cost-effective drive and control solution.

Enclosure Options

The following enclosure types are available for PowerFlex 700H and 700S
drives:

Drive

AC Input Range

HP Range

kW Range

700H

380-500V

200-2300

132-1600

525-690V

150-2400

160-2000

700S

380-500V

200-1250

132-800

525-690V

150-1600

160-1500

Drive

Enclosure
Code

Enclosure Type NEMA/UL Rating

Description

700H

A

Rittal TS 8
Modular

IP21, NEMA/UL Type 1

Single Door - Freestanding,
Light Grey (RAL 7035)

B

MCC Style

IP20, NEMA/UL Type 1

Single Door - Freestanding,
Roll-in, Roll-out power
structure

H

Rittal TS 8
Modular

IP54, NEMA/UL Type 12

(1)

Single Door - Freestanding,
Filters in Door and Roof Vent

J

No enclosure

IP00, NEMA/UL Type Open

With Conformal Coated
Circuit Boards

K

MCC Style

IP20, NEMA/UL Type 1

Single Door - Freestanding,
Roll-in, Roll-out power
structure, with Conformal
Coated Circuit Boards

M

Rittal TS 8
Modular

IP21, NEMA/UL Type 1

Single Door - Freestanding,
Light Grey (RAL 7035), with
Conformal Coated Circuit
Boards

N

No enclosure

IP00, NEMA/UL Type Open

W

Rittal TS 8
Modular w/
Conformal Coat

IP54, NEMA/UL Type 12

Single Door - Freestanding,
Filters in Door and Roof Vent
