Lifting and Mounting Instructions
B-11
2. For AC input frame 14 drives only, verify that the holes on the lifting
angles and the four metal connecting plates mounted to the rails between
the enclosures are properly aligned and secure the enclosure sections
using the bolts, washers, nuts and screws provided.
Two M10 bolts, nuts and washers.
Eight M8x20 screws and washers.
Note: Enclosure panels not shown for clarity only.
