Specifications
A-19
Table A.M 540 Volt DC Input Frames 9 - 14 Drive Protection Devices
Table A.N 650 Volt DC Input Frames 9 - 14 Drive Protection Devices
Drive Catalog Number Frame
kW Rating
DC Input Ratings
Fuse
Bussmann Style Fuse
ND
HD
Amps
20xH261
9
132
-
307
500
170M6608
-
110
241
500
170M6608
20xH300
9
160
-
353
630
170M6610
-
132
288
630
170M6610
20xH385
10
200
-
453
700
170M6611
-
160
353
700
170M6611
20xH460
10
250
-
541
900
170M6613
-
200
453
900
170M6613
20xH500
10
250
-
589
500 (2 per phs)
170M6608
-
250
494
500 (2 per phs)
170M6608
20xH590
11
315
-
695
550 (2 per phs)
170M6609
-
250
612
550 (2 per phs)
170M6609
20xH650
11
355
-
765
630 (2 per phs)
170M6610
-
315
695
630 (2 per phs)
170M6610
20xH730
11
400
-
859
700 (2 per phs)
170M6611
-
355
765
700 (2 per phs)
170M6611
20xH820
12
450
-
965
700 (2 per phs)
170M6611
-
400
859
700 (2 per phs)
170M6611
20xH920
12
500
-
1083
550 (3 per phs)
170M6609
-
450
965
550 (3 per phs)
170M6609
20xH1K0
12
560
-
1213
630 (3 per phs)
170M6610
-
500
1083
630 (3 per phs)
170M6610
20xH1K1
13
630
-
1354
2400
170M7107
-
560
1213
2400
170M7107
20xH1K3
13
710
-
1530
2400
170M7107
-
630
1354
2400
170M7107
20xH1K4
13
800
-
1707
2400
170M7107
-
710
1413
2400
170M7107
20xH1K7
(1)
(1)
Not available with 700S Control.
14
1000
-
2084
–
170M8610
-
900
1883
–
170M8610
20xH2K1
(1)
14
1200
-
2531
–
170M8610
-
1100
2284
–
170M8610
20xH2K7
(1)
14
1600
-
3178
–
170M8610
-
1300
2708
–
170M8610
Drive Catalog Number Frame
HP Rating
DC Input Ratings
Fuse
Bussmann Style Fuse
ND
HD
Amps
20xJ261
9
200
-
294
500
170M6608
-
150
231
500
170M6608
20xJ300
9
250
-
338
630
170M6610
-
200
294
630
170M6610
20xJ385
10
300
-
434
700
170M6611
-
250
338
700
170M6611
20xJ460
10
350
-
519
900
170M6613
-
300
434
900
170M6613
20xJ500
10
450
-
564
500 (2 per phs) 170M6608
-
350
474
500 (2 per phs) 170M6608
20xJ590
11
500
-
666
550 (2 per phs) 170M6609
-
450
587
550 (2 per phs) 170M6609
20xJ650
11
500
-
733
630 (2 per phs) 170M6610
-
500
666
630 (2 per phs) 170M6610
20xJ730
11
600
-
824
700 (2 per phs) 170M6611
-
500
733
700 (2 per phs) 170M6611
20xJ820
12
700
-
925
700 (2 per phs) 170M6611
-
600
824
700 (2 per phs) 170M6611
