Rockwell Automation 20D PowerFlex 700H and 700S Frame 9-14 Drives Installation - A4 Size User Manual
Page 30
2-4
PowerFlex
®
700H Control Wiring
I/O Cable Grounding
When installing shielded multi-conductor for analog and digital I/O, strip
the cable at such a distance from the terminal plug so you can fix the shield
to the cable clamp for grounding.
Position the
exposed shield so
it can fixed to the
clamp.
Note: This clamp is not designed for strain relief.
