5-4 Ladder Logic Programming—Including Reading Inputs
Example Ladder Logic
Programs
The following are example ladder logic programs for an SMP-3 solid-
state overload relay.
Important: Refer to the user manual for your SCANport product for
specific I/O definitions. Different SCANport products have different
Logic Command, Logic Status, Reference, and Feedback I/O
interpretations.
!
ATTENTION: The example ladder logic program
shown in this manual is intended solely for purpose of
example. Because there are many variables and
requirements associated with any particular installation,
Rockwell Automation does not assume responsibility or
liability (to include intellectual property liability) for
actual use based upon the example shown in this
publication.
