Publication 2100-UM001B-EN-P – January 2001
B-22 DeviceNet to SCANport Communication Module with Digital Inputs Parameters
33 Peer Flt Action Fault
Zero Data
Hold Last
Fault Cfg
Fault Yes No Determines the action the adapter should
instruct the SCANport product to take if the
adapter does not receive peer input in the
allowed time.
34 Peer Node to
Inp
0-63 0 Yes No Determines the node address of the node
producing I/O for the adapter to receive.
Important: This parameter cannot be changed
when the Peer Inp Enable (36) parameter is On.
35 Peer Inp Time-
out
.01-180.00 sec 10.00 Yes No Determines the time out time. If the adapter
does not receive input from the peer node in this
amount of time, it will do what is selected in
Peer Flt Action (33) parameter.
36 Peer Inp
Enable
Off, On Off Yes No Off = Disables peer input communications.
On = Enables peer input communications.
37 Peer Inp Sta-
tus
Off
Waiting
Running
Faulted
NA No No Displays the status of the consumed peer input
connection.
38 Peer A Output Off
Cmd/Ref
DL A Input
DL B Input
DL C Input
DL D Input
DL A Output
DL B Output
DL C Output
DL D Output
Off Yes No Determines the source of peer A output data in
the SCANport product.
Important: This parameter cannot be changed
when the Peer Out Enable (40) parameter is On.
# Name
Valid Values/
Settings
Default Writable
Reset or
Power
Cycle
Description
Important: For information on accessing and editing parameters, refer to Chapter 3, Configuring the DeviceNet to SCANport
Communication Module with Digital Inputs.
!
ATTENTION:Risk of severe
bodily injury or equipment
damage exists. The Peer Flt
Action (33) parameter allows
the user to change the default
configuration that would allow
the module and associated
drive to continue to operate if
communication is lost.
Precautions should be taken
to assure that your settings for
these parameters and your
application do not create a
hazard of bodily injury or
equipment damage.
