Publication 2100-DU021B-EN-P—January 2004
B-26 DeviceNet to SCANport Communication Module with Digital Inputs Parameters
M-S Output Parameter Configurations
The M-S Output parameter has the following five configurable bits.
Figure 6 Bits and Corresponding I/O
When you enable the Cmd/Stat (4) or datalink (5-8) parameter(s) in the adapter,
you must set the corresponding bit in the M-S Output (25) parameter if you
want the output data to be sent to the scanner or master device.
01110 xxxx1 6 6 6 6/0 6/0
01111 xxxx1 8 8 8 8/0 8/0
10000 xxxx1 2 2 2 2/0 2/0
10001 xxxx1 4 4 4 4/0 4/0
10010 xxxx1 4 4 4 4/0 4/0
10011 xxxx1 6 6 6 6/0 6/0
10100 xxxx1 4 4 4 4/0 4/0
10101 xxxx1 6 6 6 6/0 6/0
10110 xxxx1 6 6 6 6/0 6/0
10111 xxxx1 8 8 8 8/0 8/0
11000 xxxx1 4 4 4 4/0 4/0
11001 xxxx1 6 6 6 6/0 6/0
11011 xxxx1 8 8 8 8/0 8/0
11100 xxxx1 6 6 6 6/0 6/0
11101 xxxx1 8 8 8 8/0 8/0
11110 xxxx1 8 8 8 8/0 8/0
11111 xxxx1 10 10 10 10/0 10/0
ADAPTER
CONFIGURATION ALLOCATION (Number Of Words)
Data Size Sent From The Controller To The Adapter
M-S Input M-S
Output Poll Only COS Only Cyclic
Only Poll &
COS Poll &
Cyclic
xxx0, 0 0 0 0
datalink D
datalink C
datalink B
datalink A
Stat/Fdbk
0 = Peer or other output
1 = Master-Slave output
